Modular Threading Design
Designed to meet diverse machining requirements, this design features highvibration
resistance, excellent interference resistance, a long service life, and superior stability.
Perfect Fit: No Chipping of the Cutting Edge
The cutting head undergoes heat treatment prior to threading, and a specialized threadingprocess
ensures that no physical deformation occurs between the screw threads and the cutting edge.
The cutting edge fits perfectly into its seat, preventing chipping.
|
Cat.No |
Teeth |
D |
d | L | L1 | a | Insert | Clamp piece | Clamp screw | Wrench |
|
EMR-C12-4R12-120 EMR-C12-4R13-120 |
1 1 |
12 13 |
12 12 |
120 120 |
40 40 |
4 4 |
RPMW/T0802MO |
Y-4R |
M3×7 |
T10 |
|
EMR-C16-4R16-120 EMR-C16-4R16-160
EMR-C15.6-4R16-160
EMR-C15.6-4R16-200
EMR-C16-4R17-200
EMR-C19-4R20-160
EMR-C19-4R20-200 EMR-C20-4R21-200 |
2 2 2 2 2 2 2 2 2 2 2 2 2 |
16 16 16 16 16 17 17 20 20 20 20 21 21 |
16 16 15.6 16 15.6 16 16 20 19 20 19 20 20 |
120 160 160 200 200 160 200 160 160 200 200 160 200 |
40 40 40 40 50 40 50 50 50 50 50 50 50 |
4 4 4 4 4 4 4 4 4 4 4 4 4 |
RPMW/T0802MO |
Y-4R |
M3×7 |
T10 |
|
EMR-C20-5R20-160 EMR-C20-5R20-200 EMR-C20-5R21-160
EMR-C20-5R21-200 EMR-C20-5R25-160 EMR-C24-5R25-160 EMR-C25-5R25-200 EMR-C25-5R25-250 EMR-C20-5R25-200 EMR-C24-5R25-200
EMR-C24-5R25-250 EMR-C25-5R26-200
EMR-C25-5R26-250 EMR-C25-5R30-160 EMR-C25-5R30-200 EMR-C25-5R30-250 EMR-C25-5R30-300 EMR-C32-5R30-300 EMR-C32-5R35-160 EMR-C32-5R35-200 EMR-C32-5R35-250 EMR-C32-5R35-300 EMR-C32-5R35-350
EMR-C32-5R35-400 EMR-C32-5R40-200 EMR-C32-5R40-250 EMR-C32-5R40-300 EMR-C32-5R40-350 |
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2/3 2/3 2/3 3 3 3 4 4 4 4 4 |
20 20 21 21 25 25 25 25 25 25 25 25 26 26 26 30 30 30 30 30 30 35 35 35 35 35 35 40 40 40 40 40 |
20 20 20 20 25 20 24 25 25 20 24 24 25 25 25 20 25 25 25 25 32 32 32 32 32 32 32 32 32 32 32 32 |
160 200 160 200 160 160 160 200 250 200 200 250 160 200 250 120 160 200 250 300 300 160 200 250 300 350 400 160 200 250 300 350 |
50 50 50 50 50 50 50 75 60 50 50 50 50 50 50 40 50 50 60 60 60 50 50 60 60 60 60 50 50 60 60 60 |
5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 |
RPMTW1003MOE |
Y-5R |
M4×10 |
T15 |
