| Cat.No |
φD |
ap |
H |
L1 |
φC |
d1 |
Φd |
T |
Insert | Clamp screw | Wrench |
|
SMP-80-06-8T-B22 |
80 |
6 |
40 |
22 |
45 |
32 |
22 |
2X4 |
SPMG050204 |
TS2003 |
T6 |
|
SMP-80-08-8T-B22 |
80 | 8 | 40 | 22 | 45 | 32 | 22 | 2X4 |
SPMG060204 |
TS2202 |
T6 |
|
SMP-80-10-8T-B22 |
80 | 10 | 40 | 22 | 45 | 32 | 22 | 2X4 | SPMG060204 | TS2202 | T6 |
|
SMP-80-12-8T-B22 |
80 | 12 | 40 | 22 | 45 | 32 | 22 | 2X4 |
SPMG07T308 |
TS2511 |
T8 |
|
SMP-100-06-10T-B27 |
100 |
6 |
40 |
22 |
50 |
32 |
27 |
2X5 |
SPMG050204 |
TS2003 |
T8 |
|
SMP-100-08-10T-B27 |
100 | 8 | 40 | 22 | 50 | 32 | 27 | 2X5 |
SPMG060204 |
TS2202 |
T8 |
|
SMP-100-10-10T-B27 |
100 | 10 | 40 | 22 | 50 | 32 | 27 | 2X5 | SPMG060204 | TS2202 | T8 |
|
SMP-100-12-10T-B27 |
100 | 12 | 40 | 22 | 50 | 32 | 27 | 2X5 |
SPMG07T308 |
TS2511 |
T8 |
|
SMP-100-14-10T-B27 |
100 | 14 | 40 | 22 | 50 | 32 | 27 | 2X5 |
SPMG090408 |
TS3504 |
T15 |
|
SMP-100-16-10T-B27 |
100 | 16 | 40 | 22 | 50 | 32 | 27 | 2X5 | SPMG090408 | TS3504 | T15 |
|
SMP-125-06-12T-B32 |
125 |
6 |
45 |
25 |
70 |
46 |
32 |
2X6 |
SPMG050204 |
TS2003 |
T6 |
|
SMP-125-08-12T-B32 |
125 | 8 | 45 | 25 | 70 | 46 | 32 | 2X6 |
SPMG060204 |
TS2202 |
T6 |
|
SMP-125-10-12T-B32 |
125 | 10 | 45 | 25 | 70 | 46 | 32 | 2X6 | SPMG060204 | TS2202 | T6 |
|
SMP-125-12-12T-B32 |
125 |
12 |
45 | 25 | 70 | 46 | 32 | 2X6 |
SPMG07T308 |
TS2511 |
T8 |
|
SMP-125-14-12T-B32 |
125 |
14 |
45 | 25 | 70 | 46 | 32 | 2X6 |
SPMG090408 |
TS3504 |
T15 |
|
SMP-125-16-12T-B32 |
125 |
16 |
45 | 25 | 70 | 46 | 32 | 2X6 | SPMG090408 | TS3504 | T15 |
|
SMP-125-18-10T-B32 |
125 |
18 |
45 | 25 | 70 | 46 | 32 |
2X5 |
SPMG110408 |
TS4006 |
T15 |
|
SMP-125-20-10T-B32 |
125 |
20 |
45 | 25 | 70 | 46 | 32 | 2X5 | SPMG110408 | TS4006 | T15 |
|
SMP-125-25-10T-B32 |
125 | 25 | 45 | 25 | 70 | 46 | 32 | 2X5 |
SPMG140512 |
TS5009 |
T20 |
|
SMP-160-12-16T-B40 |
160 |
12 |
50 |
28 |
80 |
52 |
40 |
2X8 |
SPMG07T308 |
TS2511 |
T8 |
|
SMP-160-16-16T-B40 |
160 | 16 | 50 | 28 | 80 | 52 | 40 | 2X8 |
SPMG090408 |
TS3504 |
T15 |
|
SMP-160-18-12T-B40 SMP-160-20-12T-B40 |
160 |
18 20 |
50 | 28 | 80 | 52 | 40 |
2X6 |
SPMG110408 |
TS4006 |
T15 |
| SMP-160-25-12T-B40 | 160 | 25 | 50 | 28 | 80 | 52 | 40 | 2X6 |
SPMG140512 |
TS5009 |
T20 |
|
SMP-200-16-18T-B40 |
200 |
16 |
50 |
28 |
80 |
52 |
40 |
2X9 |
SPMG090408 |
TS3504 |
T15 |
|
SMP-200-18-14T-B40 SMP-200-20-14T-B40 |
200 |
18 20 |
50 | 28 | 80 | 52 | 40 |
2X7 |
SPMG110408 |
TS4006 |
T15 |
|
SMP-200-25-14T-B40 |
200 | 25 | 50 | 28 | 80 | 52 | 40 | 2X7 |
SPMG140512 |
TS5009 |
T20 |
