1、Strong torque power
2、High concentricity and run-out accuracy,suitable for fine finishing machining.
|
Specification |
D1 |
D2 |
D3 |
D4 |
L1 |
L2max |
L2min |
V |
L3 |
L4 |
G |
|
|
HSK40E |
HM6-75 |
6 |
25 |
28 |
34 |
75 |
37.5 |
27.5 |
10 |
28 |
55 |
M5X0.8 |
|
HM8-70 |
8 |
27 |
30 |
34 |
70 |
37.5 |
27.5 |
10 |
28 |
50 |
M5X0.8 |
|
|
HM10-75 |
10 |
29 |
32 |
34 |
75 |
42.5 |
32.5 |
10 |
34 |
55 |
M5X0.8 |
|
|
HM12-85 |
12 |
31 |
34 |
34 |
85 |
47.5 |
37.5 |
10 |
一 |
65 |
M5X0.8 |
|
|
HSK50E |
HM6-70 |
6 |
25 |
28 |
40 |
70 |
37.5 |
27.5 |
10 |
28 |
44 |
M5X0.8 |
|
HM8-70 |
8 |
27 |
30 |
40 |
70 |
37.5 |
27.5 |
10 |
28 |
44 |
M6X¹.0 |
|
|
HM10-80 |
10 |
29 |
32 |
40 |
80 |
42.5 |
32.5 |
10 |
34 |
54 |
M6X1.0 |
|
|
HM12-85 |
12 |
31 |
34 |
40 |
85 |
47.5 |
37.5 |
10 |
44 |
59 |
M6X1.0 |
|
|
HM16-90 |
16 |
35 |
38 |
60 |
90 |
52.5 |
42.5 |
10 |
30 |
64 |
M6X1.0 |
|
|
HM20-90 |
20 |
40 |
43 |
一 |
90 |
52.5 |
42.5 |
10 |
一 |
64 |
M6X1.0 |
